HIGHSIDER Comet-Low LED Headlight

HIGHSIDER LED low beam headlight COMET-LOW, E-tested

Tiny little LED low beam headlight in a matt black aluminium housing with sturdy steel bracket. Thanks to the use of modern LED technology, it is possible to achieve the smallest possible housing dimensions while at the same time achieving the highest possible luminous efficacy. The three powerful SMD LEDs with oval lens produce a symmetrical bright light for increased visibility. Another advantage is a significant reduction in the load on the alternator due to the low power consumption.

Overview special features:
- Tiny: Only 3.6 cm high and 5.5 cm wide
- Robust: Thanks to aluminum housing and holder made of steel
- Powerful SMD- LEDs for more visibility
- Sporty design and light color
- Low power consumption relieves the alternator
- Together with the COMET-HIGH a true dream team (optionally available)

Our highlights - give your bike a distinctive style! The unusual design and perfect technology of the HIGHSIDER headlight series make it a highlight in any case!

Dimensions:
Height: 36 mm
Width: 55 mm
Depth: 70 mm
Height lens: 24 mm
Width lens: 42 mm
Mounting hole spacing: 55 mm
Mounting holes on side: M4

Dimensions of box:
Width: 44.5 mm
Depth: 11 mm
Height: 17 mm
Weight: 128 g

Connections:
Red = positive (+)
The red wire connects to ignition positive (+)
Black = ground (-)

Scope of delivery: 1 piece incl.
1x screw
1x U- washer
1x nut

Optional available:
Best. No.: 223-452 HIGHSIDER LED spotlight COMET- HIGH

Notes:
Never connect the spotlight without the supplied black electronics box (voltage control)!
